Chessie Flyer |
||
|---|---|---|
| #106 | a 27' gaff rigged sharpie ketch | Build in PLYWOOD |
| Characteristics | |||
|---|---|---|---|
| Length overall (on deck) | 26'-11" | ||
| Length overall (including bowsprit) | 30'-7" | ||
| Waterline length | 24'-0" | ||
| Beam | 7'-11" | ||
| Freeboard forward | 3'-3" | ||
| Freeboard aft | 2'-4" | ||
| Draft (board up) | 9" | ||
| Draft (board down) | 3'-9" | ||
| Height (board up to cabin top) | 4'-6" | ||
| Displacement | 3950 lbs. | ||
| Ballast weight | 1000 lbs. | ||
| Cabin headroom | 4'-0" | ||
| Cockpit size | 5'-6" x 5'-9" | ||
| Sleeping accommodations | 3-4 | ||
| Sail area | Main - 127 sq. ft. Foretriangle - 98 sq. ft. Mizzen - 75 sq. ft. Total - 300 sq. ft. |
||
| Hull type: Flat bottom, hard chine, double ended sharpie-type, centerboard hull with "pinkie" stern, designed for 3/8" plywood. Ballast: Interior ballast plus 1" plate steel centerboard. Sail type: Gaff rigged ketch. Power: Well mounted outboard motor to 5 HP, 15" to 20" nominal shaft. Trailer: Designed for use with Glen-L Series 6000 boat trailer plans. |
|||
