Control Shaft Drilling Diagram...
When ordering the Adjustable Plate Hardware Kit or separate Control Shafts, accompany the order with dimensions for drilling the shaft and we will drill the shaft for no extra charge. Please provide all dimensions in the diagram above. This diagram is not interactive so it will be necessary to FAX a copy or email a verbal list of dimensions.
