Amigo-FG
|
||
|---|---|---|
| #101/102 | a trailerable off shore cruiser with a classic design | Build in FIBERGLASS or STRIP PLANK WOOD |
| Characteristics | |||
|---|---|---|---|
| Length overall (on deck) | 22'-0" | ||
| Length overall (including bowsprit) | 25'-0" | ||
| Waterline length | 19'-2" | ||
| Beam | 8'-0" | ||
| Freeboard forward | 4'-2" | ||
| Freeboard aft | 2'-10" | ||
| Draft | 3'-0" | ||
| Height (to cabin top) | 8'-0" | ||
| Displacement | 5100 lbs. | ||
| Ballast weight | 1775 lbs. | ||
| Cabin headroom | 5'-10" to 6'-0" | ||
| Cockpit well | 4'-3" x 23" fwd, 18" aft | ||
| Fuel capacity | 13 gals. | ||
| Water capacity | 50 gals. | ||
| Sleeping accommodations | 4 | ||
| Sail area - Masthead rig: | Main-117 sq. ft. Foretriangle-126 sq. ft. Total: 243 sq. ft. |
||
| Sail area - Gaff rig: | Main-174 sq. ft. Jib-76 sq. ft., Total: 250 sq. ft. |
||
| Hull type: Round bilge, full keel hull, designed for
"one-off" fiberglass or strip-planked wood construction. Sail type: Masthead or gaff sloop Power: Transom-mounted outboard or inboard engine, 250 lbs. max., 5 to 10 bhp. Trailer: Designed for use with Glen-L Series 6000 boat trailer plans. |
|||
