Glen-L 19 |
||
|---|---|---|
| #120 | a 19' overnighter sloop | Build in PLYWOOD |
| Characteristics | |||
|---|---|---|---|
| Length overall | 19'-3" | ||
| Waterline length | 16'-8" | ||
| Beam | 7'-9" | ||
| Freeboard forward | 2'-11" | ||
| Freeboard aft | 2'-1/2" | ||
| Draft (board up) | 20" | ||
| Draft (board down) | 3'-10" | ||
| Height (board up to cabin top) | 5'8" | ||
| Displacement | 1900 lbs. | ||
| Hull weight (approx.) | 600 lbs. | ||
| Ballast weight | 400 lbs. | ||
| Cabin headroom | 3'-7 1/2" | ||
| Cockpit size | 5'-6" x 6'-0" | ||
| Average passengers | 2-4 | ||
| Sleeping accommodations | 4 | ||
| Sail area | Main - 82 sq. ft. Jib - 83 sq. ft. Genoa - 129 sq. ft. Totals - 165 or 211 sq. ft. |
||
| Hull type: Vee bottom hull with sheet steel centerboard and
internal ballast keel, developed for 3/8" sheet plywood. Sail type: Masthead centerboard sloop. Power: Short or long shaft outboard motor to 10 hp mounted on removable transom bracket (optional). Trailer: Designed for use with Glen-L Series 1700 boat trailer plans. |
|||
